National Electrical Code (NEC) Article 690 Practice Test

These questions are part of the practice quiz. Start practicing

• What is a requirement for microinverters according to Article 690?
• What is the voltage rating typically associated with PV systems?
• What is the purpose of overcurrent devices in PV systems?
• Which type of systems does Article 690 apply to?
• What is the general requirement for isolating devices used in PV systems regarding their listing?
• What is crucial to preventing overloads in photovoltaic (PV) systems?
• What is the primary purpose of having overcurrent devices accessible in PV system installations?
• What determines if the ratings of the PV system disconnecting means are sufficient?
• What does the term “utility grid” refer to in the context of Article 690?
• Are photovoltaic system equipment and disconnecting means allowed in bathrooms?
• What is the time limit for the highest voltage to be restricted inside the equipment post rapid shutdown initiation?
• Flexible cords connected to which component of tracking PV systems must comply with Article 400?
• In which part of PV systems is marking for conductor safety crucial?
• In what situation is the equipment grounding conductor an important component in a PV system?
• Exposed noncurrent-carrying metal parts of PV systems must be connected to what?
• Which characteristic is essential for the connectors used in photovoltaic circuits?
• What should the markings on the disconnecting means include?
• What is the key objective of conducting a PV system site assessment?
• What is the maximum distance allowed between supports for single-conductor PV wire in outdoor cable trays?
• Which scenario requires the installation of PV arc-fault circuit interrupters for safety considerations?
• Which of the following types of isolating devices is permitted for PV system equipment?
• Mating connectors in PV source circuits must be configured to be what in relation to receptacles in other electrical systems?
• How is a “PV module” defined in Article 690?
• What additional guidelines does Article 690 prescribe for battery-based systems?
• What marking requirement is specified for junction boxes in Article 690?
• What components are included in a PV system according to Article 690?
• Which section addresses the requirements for latches on enclosures for PV systems?
• Which of the following is NOT a requirement for a PV system disconnecting means?
• Which of the following best describes the role of grounding in PV systems?
• According to Article 690, what should be rated when selecting conductors?
• What type of areas are PV circuits in need of rapid shutdown typically designed to protect?
• How is the maximum dc voltage for a PV source circuit calculated?
• What is a key requirement for effective grounding in PV systems under NEC standards?
• How often are PV systems recommended to be inspected according to Article 690?
• What must the PV system disconnecting means plainly indicate?
• How does the National Electrical Code (NEC) address roof-mounted PV systems?
• Why is it necessary to connect the equipment grounding conductor to the grounding electrode system?
• PV equipment installed on detached structures, such as carports, are subject to which requirements regarding rapid shutdown?
• In terms of inverter installations, what provides optimal operational conditions?
• Where should the PV system disconnecting means be located?
• What type of circuits does Article 690 pertain to primarily?
• How does the NEC recommend addressing thermal management for inverters in PV systems?
• What is the primary function of an inverter in a PV system?
• According to Article 690, what should be the overall focus of a PV system installation?
• Which statement is true regarding mating connectors used for PV circuits?
• What information must all electrical conductors in a PV system display?
• How should junction, pull, and outlet boxes be installed behind modules or panels?
• What does a complete ac module consist of?
• To what industry standard must solar photovoltaic systems comply?
• What marking is required on the insulation of positive conductors that are nonsolidly grounded?
• How must DC conductors be routed according to the NEC for PV systems?
• What is required for disconnecting ac PV modules from circuits?
• For PV systems with an inverter generating capacity of what size, can the maximum dc voltage be documented by a licensed professional electrical engineer?
• What function is primarily hindered by improper shutdown procedures in photovoltaic systems?
• Where should a permanent label indicating the highest maximum dc voltage in a PV system be provided?
• What percentage of the maximum currents calculated must overcurrent devices for PV source circuits be sized at a minimum?
• What do the module-level power electronics in Article 690 aim to achieve?
• What is required for an isolating device to function effectively in isolating PV system equipment under load?
• What type of insulation must single-conductor PV system cables have for outdoor use?
• At what voltage level must the PV system disconnecting means be readily accessible to unqualified persons?
• What does "PV" stand for in the context of Article 690?
• What is the role of the "rapido shutdown" label in PV system installations?
• PV system dc circuits utilizing metal-clad cables installed in metal raceways can be exempt from AFCI protection when installed in what conditions?
• What must be done with grounding conductors in PV systems according to NEC guidelines?
• What does the term "series arrangement" refer to in PV modules?
• What does the equipment disconnecting means need to comply with when isolating PV system equipment?
• What type of fittings and connectors are allowed for the on-site interconnection of PV modules at the time of assembly?
• What must installation components of PV systems provide according to electrical codes?
• What type of supports can equipment be bonded to in PV systems according to regulations?
• When multiple systems are placed on a building, what must be ensured for safety?
• What labeling is required for PV system equipment?
• Mating connectors used in PV systems must have what essential feature?
• What does the rapid shutdown initiation device's “off” position indicate?
• What does Section 690.5 address in PV systems?
• What is emphasized about the accessibility of disconnecting means in a PV system?
• Why is the equipment grounding conductor critical in a non-solidly grounded PV system?
• What key safety feature is required for disconnecting means in PV systems as per Article 690?
• How should PV system DC circuits use an approved means to identify conductors that don’t rely on color coding?
• Which of the following is a safety consideration in PV installations as mentioned in Article 690?
• Which component of a PV system consolidates multiple source circuits into a single output?
• What is the maximum spacing interval allowed for grouping AC and DC conductors in a junction box for PV systems?
• What information should be included in the documentation supplied with PV systems?
• For isolating devices in PV systems, what is the maximum circuit current limit for the installation of an isolating device?
• In PV systems, what does the grounding electrode system connect to?
• What type of output circuit is considered when discussing the output of an ac module?
• In what scenario can PV system DC circuits share an equipment wiring enclosure with other non-PV systems?
• In Article 690, what aspect of PV systems does the term "grounding" refer to?
• What must buildings with PV systems that have rapid shutdown include as per regulations?
• What type of tool must be used to open mating connectors in PV source circuits above certain voltage thresholds?
• Which section of the NEC specifically relates to grounding for PV systems?
• What safety feature must PV system circuits installed on buildings include to reduce shock hazard for firefighters?
• What is the required height for the label indicating the presence of rapid shutdown in PV systems?
• What is a "power production meter" in the context of PV systems?
• Which document should be included with installed PV systems to ensure safe operation?
• What is the role of a finger safe fuse holder in PV systems?
• What does Article 690.7 focus on regarding PV systems?
• How should equipment grounding conductors for photovoltaic (PV) system circuits be sized?
• What type of wiring methods should be used for PV equipment floating on water?
• What is a critical consideration while installing roof-mounted PV systems?
• What is the minimum conductor size specified for DC circuits in Article 690?
• Which of the following is essential for preventing electrocution in PV systems?
• For PV equipment located in environments conducive to moisture, what additional safety concern must be taken into account?
• Which of the following is a requirement for PV systems regarding the controlled conductors?
• What is the primary purpose of the rapid shutdown function in PV systems?
• In PV systems requiring overcurrent protection, where must the circuit conductors be protected?
• What is the main purpose of Article 690.1?
• Which color should NOT be used for marking positive PV system DC circuit conductors?
• How are electrical conductors categorized in Article 690?
• What type of overcurrent protection is required for PV output circuits?
• Under what condition is overcurrent protection for PV system dc circuit conductors not required?
• What is the requirement for the parallel wiring of PV source circuits?
• Where should PV system DC circuits exceeding 30V or 8A be contained inside buildings?
• In PV systems, how is the maximum PV source current calculated?
• When are PV system conductors permitted to occupy the same raceway as non-PV conductors?
• What is the main purpose of a grounding electrode system in PV installations?
• What must be done if a circuit conductor is connected to a source with higher available maximum current?
• What aspect of maintenance is critical for ensuring the performance of a PV system?
• What is required for a PV system according to section 690.8?
• What type of line must be used in the diagram to indicate areas that remain energized after rapid shutdown?
• What is required to open mating connectors used in PV source circuits operating at over 30V dc or 15V ac?
• What terminology does Article 690 use for the grid receiving power from a PV system?
• What must be established for the grounding of a PV system according to Article 690?
• How must DC wiring systems be installed for safety according to Article 690?
• What happens if the equipment grounding conductor is not correctly sized according to NEC?
• What is the recommended orientation for PV panels to enhance energy efficiency?
• Which component must provide shock hazard control for firefighters during a rapid shutdown?
• Which of the following is true regarding PV system components?
• What must labels indicate in PV installations according to Section 690.54?
• Is a means required to disconnect the PV system from all wiring systems?
• What is required in locations where multiple photovoltaic systems are found in a single building?
• If a PV source circuit assembly is rated for continuous operation at 100 percent, at what percentage of its rating can it be used?
• Why is grounding important in a PV system as stated in Article 690?
• The disconnecting means for PV system equipment must be rated sufficiently for which of the following?
• What is required for the installation of PV source circuits according to Article 690?
• What is crucial for the rapid shutdown of all PV systems connected to the same device?
• What percentage must conductor sizes be calculated to ensure proper ampacity in PV systems?
• Which section of Article 690 covers the general requirements for PV systems?
• Which method is acceptable for identifying polarity in PV system DC circuit conductors at all termination points?
• Which components must comply with the requirements for controlled conductors part of a rapid shutdown in a PV system?
• What is required for rapid shutdown of PV systems as stated in Section 690.12?
• What is the maximum PV inverter output circuit current equal to?
• At what dc voltage or greater must photovoltaic systems be protected by a listed PV arc-fault circuit interrupter?
• What components must meet standards to eliminate overcurrent protection requirements?
• What is the primary purpose of Article 690 of the NEC?
• What does Section 690.4 address regarding PV systems?
• What is an essential requirement for protecting PV system conductors?
• For PV systems, where are circuits terminating on buildings not considered controlled conductors?
• What is the maximum spacing permitted for labels or markings on PV system raceways?
• What does Article 690 emphasize for PV systems installed in flood-prone areas?
• Which safety device is required in all PV systems according to Article 690?
• What should be included in the documentation for a PV installation regarding grounding?
• What is the role of a licensed professional electrical engineer in the context of maximum dc voltage documentation for PV systems?
• How is the maximum voltage for PV dc-to-dc converter circuits determined?
• Which device is NOT involved in the rapid shutdown initiation for a PV system?
• What type of overcurrent devices should be used in PV source circuits?
• What is a combiner box in a photovoltaic system?
• According to manufacturer’s instructions, what must PV system rapid shutdown systems meet in terms of equipment requirements?
• What should be the spacing interval for securing single-conductor cables in cable trays?
• How are the types of conductors used in PV systems classified?
• Within how many feet must the rapid shutdown switch be labeled specifically for solar PV systems?
• What is a module circuit as defined in Article 690?
• What must be ensured when interconnecting PV systems with utility service?
• What type of connections does Section 690 address specifically?
• What must all equipment intended for use in photovoltaic systems have applied to them?
• What is the minimum height above grade for equipment containing PV system DC circuits greater than 1,000V installed on the exterior of buildings?
• Under what condition is the grouping requirement for PV system conductors not necessary?
• What must devices used for mounting PV modules also be able to do?
• What is a critical factor in the sizing of conductors for a PV system?
• Where can electronic power converters for photovoltaic systems be mounted?
• What is required for the accessibility of junction, pull, and outlet boxes in PV systems?
• What must be marked on PV source circuits according to Article 690?
• What kind of systems require the implementation of an equipment grounding conductor?
• For the design of a PV system, which aspect must be documented and stamped by a licensed professional?
• What is the maximum allowable voltage outside the array boundary during rapid shutdown initiation within 30 seconds?
• What Article's requirements do not apply to ac modules or ac module systems?
• Are overcurrent devices for PV system dc circuits required to be readily accessible?
• How is ground-fault protection defined in Article 690?
• Which wiring methods containing photovoltaic power source conductors must be marked PHOTOVOLTAIC POWER SOURCE?
• What type of cable should be used for PV source and output circuits operating at over 30V when installed in accessible locations?
• How is the highest voltage controlled within the area boundary during a rapid shutdown?
• For PV systems that are not solidly grounded, what is permitted to be the only connection to ground for the system?
• What is the lowest-expected temperature design data source for calculating maximum PV source circuit voltage?
• What is a common requirement for PV systems regarding environmental protection?
• How can a PV system optimize energy production during installation?
• Which of the following is a purpose of the equipment grounding conductor in PV systems?
• Which type of structures do PV system dc circuits installed in metal raceways not require AFCI protection when located on?
• What type of device must be capable of separating PV system DC circuits from other circuits?
• What type of enclosures is required for PV system DC circuits above a certain voltage within buildings?
• What should be verified for equipment grounding conductors in PV systems during inspections?
• In the context of PV systems, what is the defined distance from the array for the term array boundary?
• Where are wiring methods with PV system DC circuits greater than 1,000V not permitted?
• What is an important consideration for panels located above a specific voltage?
• To which system circuits do bonding requirements apply according to the defined standards?
• What is the minimum system voltage specified for PV systems?
• Ground-mounted PV system circuits that enter buildings housing PV equipment are subject to which requirements?
• Where should the rapid shutdown initiation device be located for one-family and two-family dwellings?
• What is emphasized regarding conductor ratings in Article 690?
• Which containers must be used for supporting single-conductor PV wires in outdoor locations?
• Which aspect must be factored into circuit sizing of PV systems?
